Compared with the standard size filters,The high flow filters have a larger filter area and save time for replacement. High dirt holding capacity for a longer service life and lower replacement cost. We have full replacements for high flow filter systems from major international brands.
Main applications
RO Pre filtration,process water (circulating water, condensed water), ground, regeneration, waste water, seawater desalination, petrochemical, power plant water treatment system security filtration.
| Materials and working environment | |
| Components | Materials |
| Filter Membrane | Polypropylene / Glass Fiber / Polyethylene |
| Support Media | Polypropylene / Polyester / Nylon |
| Inner Core | Polypropylene / Stainless Steel / Polyethylene Protection Mesh / PET |
| Outer Cage | Polypropylene / Stainless Steel / Polyethylene Protection Mesh / PET |
| End Cap | Polypropylene / PET |
| O-ring | Silicone / Viton / EPDM / PTFE |
| OD | 165 / 152 / 131 / 83 |
| ID | 89 / 63 / 40 |
| Length (inch) | 10 / 20 / 40 / 60 |
| Removal Ratings (μm) | 0.5 / 1 / 3 / 5 / 10 / 20 / 40 / 70 |
| Effective Filter Area | ≥ 6m² / 40in@152mm |
| Maximum Operating Temperature | 90℃ / 194F |
| Maximum Positive Differential Pressure | 0.35Mpa / 23℃@165mm / 152mm; 0.4Mpa / 23℃@131mm; 0.4Mpa / 23℃@83mm |
High Dirt Holding Capacity High Flow Filters
Additional Layer is added for dirt-holiding, Gradient filtering layer collocation, the service life is 3-5 times longer than the regular type. The internal and external support has high strength and higher pressure resistance.
Regular High Flow Filters
Made of Conventional internal and external support and filter membranes.
