Jul. 21, 2023
Stainless steel pleated filter cartridges are mainly made from two main filtering materials: stainless steel woven mesh and stainless steel fiber sintered felt. The pleated filter cartridges made from stainless steel woven mesh have smooth channels, are easy to clean, and possess characteristics like high temperature resistance, corrosion resistance, no wire shedding, and long filtration cycles. On the other hand, stainless steel fiber sintered felt is a porous deep filtration material made from stainless steel fibers through high-temperature sintering. The pleated filter cartridges made from this material have high porosity, excellent breathability, strong pollutant retention capacity, and high regeneration ability, making them widely used in filtration systems in industries such as petrochemicals and chemical engineering.
Characteristics of stainless steel pleated filter cartridges:
1. High strength and strong pressure resistance (less likely to shed particles).
2. Uniform structure, high porosity, low filtration resistance, and good permeability.
3. Strong temperature resistance (suitable for steam filtration).
4. Excellent corrosion resistance (no rust in water and chemical liquids).
5. Long service life (several times that of ordinary membrane filter cartridges).
6. High hardness, easy to backwash (online backwashing is achievable).
7. Strong affinity for human contact.
8. Convenient forming and processing, can be processed into various shapes according to requirements.
Pleated filter cartridges demonstrate excellent filtration performance for particles ranging from 1 to 500 micrometers in both liquids and gases. They offer a large flow rate per unit area and can be reused after cleaning.
The cartridges are made from single or multiple layers of metal mesh, with the number of layers and mesh sizes determined based on specific usage conditions and purposes. They have high filtration accuracy, excellent pressure resistance, and good straightness. The stainless steel material ensures there are no burrs, ensuring a long service life.
Main Connection Methods:
Standard interfaces (such as 222, 220, 226), quick-connect interfaces, threaded connections, flange connections, rod connections, and custom-made interfaces.
Application:
1. Petrochemicals, oilfield pipeline filtration.
2. Fuel filtration in refueling equipment and engineering machinery.
3. Water treatment equipment filtration.
4. Pharmaceuticals and food processing fields.
